Placa Base Asus Intel Pro B460M – C – Csm Socket 1200 Ddr4 X4 Max 128Gb 2933Mhz Display Port Hdmi D – Sub Matx

Placa Base Asus Intel Pro B460M – C MGS0000001405

Cpu
intel® socket lga1200 for 10th gen intel® core – pentium® gold and
celeron® processors*
supports intel® 14nm cpu
supports intel® turbo boost technology 2.0 and intel® turbo boost max
technology 3.0**
* refer to www.asus.com for cpu support list.
** intel® turbo boost max technology 3.0 support depends on the cpu
types.
chipset intel® b460 chipset
memory
4 x dimm – max. 128gb – ddr4 2933 – 2800 – 2666 – 2400 – 2133mhz – non – ecc – un –
buffered memory*
dual channel memory architecture
supports intel® extreme memory profile (xmp)
optimem
*for 10th gen intel® processors – only core i9 – i7 cpus support
2933 – 2800 – 2666 – 2400 – 2133 natively – others will run at the maximum transfer
rate of ddr4 2666mhz.
*refer to www.asus.com for the memory qvl (qualified vendors lists).
graphics
2 x displayport 1.4**
1 x d – sub
1 x hdmitm 1.4b
*graphics specificatións may vary between cpu types.
**support displayport 1.4 with max. resolutión of 4096 x 2304 @60hz.
please refer to www.intel.com for any update.
expansión slots
intel® 10th gen processors
1 x pcie 3.0 x16 slot (support x16 mode)
intel® b460 chipset
2 x pcie 3.0 x1 slots
1 x pci slot
storage
total supports 2 x m.2 slots and 6 x sata 6gb – s ports
intel® b460 chipset
m.2_1 slot (key m) – type 2242 – 2260 – 2280 (supports pcie 3.0 x4 & sata
modes)*
m.2_2 slot (key m) – type 2242 – 2260 – 2280 (supports pcie 3.0 x4 mode)**
6 x sata 6gb – s ports
intel® rapid storage technology supports raid 0 -1 -5 -10
intel® optane memory ready
* when a device in sata mode is installed on the m.2_1 socket – sata6g_1
port cannot be used.
** only the m.2_2 supports irst.
ethernet
1 x intel® i219v 1gb ethernet
asus languard
usb
rear usb (total 6 ports)
4 x usb 3.2 gen 1 ports (4 x type – a)
2 x usb 2.0 ports (2 x type – a)
front usb (total 6 ports)
1 x usb 3.2 gen 1 header supports additiónal 2 usb 3.2 gen 1 ports
2 x usb 2.0 headers support additiónal 4 usb 2.0 ports
audio
pulgadasrealtek alc887 7.1 – channel high definitión audio codec* –
jack – detectión – multi – streaming – front panel jack – retasking – supports up
to 24 – bit – 192khz playback pulgadas
*a chassis with an hd audio module in the front panel is required to
support 7.1 – channel audio output.
back panel i – o ports
4 x usb 3.2 gen 1 ports (4 x type – a)
2 x usb 2.0 ports (2 x type – a)
2 x displayport
1 x d – sub port
1 x hdmitm port
1 x intel® i219v 1gb ethernet port
3 x audio jacks
1 x ps – 2 keyboard (purple) port
1 x ps – 2 mouse (green) port
internal i – o connectors
fan and cooling related
1 x 4 – pin cpu fan header
2 x 4 – pin chassis fan headers
power related
1 x 24 – pin main power connector
1 x 8 – pin +12v power connector
storage related
2 x m.2 slots (key m)
6 x sata 6gb – s ports
usb
1 x usb 3.2 gen 1 header supports additiónal 2 usb 3.2 gen 1 ports
2 x usb 2.0 headers support additiónal 4 usb 2.0 ports
miscellaneous
1 x clear cmos header
1 x chassis intrude header
2 x com port headers
1 x front panel audio header (aafp)
1 x lpc debug header
1 x lpt header
1 x mono – out header(with amp ic)
1 x speaker header
1 x spi tpm header (14 – 1pin)
1 x 10 – 1 pin system panel header
special features
asus ez diy
– box headers
bespoke motherboard design & business focused features :
– asus self recovering bios
– asus event log
– asus commercial bios kit
– anti – moisture
– 24 – 7 reliability
– overcurrent protectión
software features
asus exclusive software
it management software supported
– asus control center express(acce)
bios 128mb flash rom – uefi ami bios
manageability wol by pme – pxe
operating system windows® 10 (64 – bit)
form factor matx form factor
9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)

Comprar Placa Base Asus Intel Pro B460M – C MGS0000001405
