Placa Base Asus Amd Prime B450M – A MGS0000001140
Placa base micro – atx amd b450 (ryzen am4) con soporte m.2 – hdmi – dvi – d –
sub – sata 6 gbps – 1 gb ethernet – usb 3.2 gen. 2 de tipo a – bios flashback
y aura sync rgb
refrigeración completa: disipador pch y fan xpert 2+.
conectividad de alta velocidad: soporte m.2 – 1 gb ethernet – usb 3.2 gen. 2
de tipo a.
5x protectión iii: diversas características hardware que protegen. el
sistema.
iluminación aura sync rgb: conector para tiras led rgb que puedes
sincronizar con el el cada vez mayor número de dispositivos aura sync.
cpu
amd am4 socket for amd ryzen 5000 series – 4000 g – series – 3rd – 2nd – 1st
gen amd ryzen – 2nd and 1st gen amd ryzen with radeon vega
graphics – athlon with radeon vega graphics processors *
* refer to www.asus.com for cpu support list
chipset
amd b450
memory
3rd – 2nd – 1st gen amd ryzen – 2nd and 1st gen amd ryzen with radeon
vega graphics – athlon with radeon vega graphics processors
4 x dimm – max. 128gb – ddr4 4400(o.c) – 4000(o.c.) – 3866(o.c.) – 3733
(o.c.) – 3600(o.c.) – 3466(o.c.) – 3400(o.c.) – 3300(o.c.) – 3200(o.c.) – 3000
(o.c.) – 2800(o.c.) – 2666 – 2400 – 2133 mhz un – buffered memory *
dual channel memory architecture
ecc memory (ecc mode) support varies by cpu.
* refer to www.asus.com for the memory qvl (qualified vendors lists).
* the maximum memory frequency supported varies by processor.
graphic
integrated graphics in the 2nd and 1st gen amd ryzen with radeon
vega graphics – athlon with radeon vega graphics processors *
1 x d – sub
1 x dvi – d
1 x hdmi 2.0b
*graphics specificatións may vary between cpu types.
expansión slots
3rd – 2nd – 1st gen amd ryzen processors
1 x pcie 3.0 x16 (x16 mode)
2nd and 1st gen amd ryzen with radeon vega graphics processors
1 x pcie 3.0 x16 (x8 mode)
amd athlon with radeon vega graphics processors
1 x pcie 3.0 x16 (x4 mode)
amd b450 chipset
2 x pcie 2.0 x1
storage
total supports 1 x m.2 slot(s) and 6 x sata 6gb – s ports
3rd – 2nd – 1st gen amd ryzen – 2nd and 1st gen amd ryzen with radeon
vega graphics : *1
1 x m.2 socket 3 – with m key – type 2242 – 2260 – 2280 – 22110 storage devices
support (sata & pcie 3.0 x 4 mode)
athlon with radeon vega graphics processors : *1
1 x m.2 socket 3 – with m key – type 2242 – 2260 – 2280 – 22110 storage devices
support (sata mode)
3rd – 2nd – 1st gen amd ryzen – 2nd and 1st gen amd ryzen with radeon
vega graphics – athlon with radeon vega graphics processors :
2 x sata 6gb – s port(s) –
support raid 0 – 1 – 10
amd b450 chipset :
4 x sata 6gb – s port(s) –
support raid 0 – 1 – 10
lan
realtek® rtl8111h
asus languard
audio
realtek alc887 – 897 7.1 – channel high definitión audio codec *
– supports : jack – detectión – multi – streaming – front panel jack – retasking – up
to 24 – bit – 192khz playback
audio feature :
– led – illuminated design
– audio shielding
– dedicated audio pcb layers
– premium japanese audio capacitors
* choose the chassis with hd audio module in front panel to support 8 –
channel audio output.
usb ports
rear usb port ( total 6 )
2 x usb 3.2 gen 2 (up to 10gbps) port(s)(2 x type – a)
4 x usb 3.2 gen 1 port(s)(4 x type – a)
front usb port ( total 6 )
2 x usb 3.2 gen 1 port(s)
4 x usb 2.0 port(s)
software features
asus exclusive software
armoury crate
– aura creator
– aura sync
ai suite 3
– performance and power saving utility
turbov evo
epu
digi+ vrm
fan xpert 2+
pc cleaner
– ez update
– system informatión
asus cpu – z
ai charger
asus ez installer
daemon tools
nortón anti – virus software (free trial for 60 days)
winrar
uefi bios
asus ez diy
– asus crashfree bios 3
– asus ez flash 3
– asus uefi bios ez mode
asus special features
asus 5x protection iii
– asus digi+ vrm
– asus languard
– asus overvoltage protectión
– asus safeslot core
– asus stainless – steel back i – o
asus q – design
– asus q – dimm
– asus q – slot
asus thermal solutión
– aluminum heatsink design
asus ez diy
– bios flashback buttón
– bios flashback led
aura sync
– aura rgb header
asus lighting control
back i – o ports
1 x ps – 2 keyboard – mouse combo port(s)
1 x dvi – d
1 x d – sub
1 x hdmi
1 x lan (rj45) port(s)
2 x usb 3.2 gen 2 (teal blue) (2 x type – a)
4 x usb 3.2 gen 1 (blue) type – a
3 x audio jack(s)
1 x bios flashback buttón(s)
internal i – o ports
1 x cpu fan connector(s) (1 x 4 – pin)
2 x chassis fan connector(s) (2 x 4 – pin)
1 x usb 3.2 gen 1(up to 5gbps) connector(s) support(s) additiónal 2 usb 3.2
gen 1 port(s) (19 – pin)
2 x usb 2.0 connector(s) support(s) additiónal 4 usb 2.0 port(s)
1 x m.2 socket 3 with m key – type 2242 – 2260 – 2280 – 22110 storage devices
support (sata & pcie 3.0 x 4 mode)
1 x spi tpm header
1 x com port(s) connector(s)
6 x sata 6gb – s connector(s)
1 x s – pdif out header(s)
1 x 24 – pin eatx power connector(s)
1 x 8 – pin atx 12v power connector(s)
1 x front panel audio connector(s) (aafp)
1 x system panel(s)
1 x clear cmos jumper(s)
1 x com port header
1 x speaker connector
1 x rgb header
accessories
user´s manual
i – o shield
2 x sata 6gb – s cable(s)
1 x m.2 screw package
1 x supporting dvd
bios
256 mb flash rom – uefi ami bios
operating system
windows® 10 64 – bit
windows® 7 64 – bit *2
form factor
matx form factor
9.6 inch x 9.5 inch ( 24.4 cm x 24 cm )
Comprar Placa Base Asus Amd Prime B450M – A MGS0000001140
MGS0000001140,90MB15Z0-M0EAY0,4718017924986
